24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator - LBC24360ST

This product has been discontinued by the manufacture and is no longer available.

24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator

Model: LBC24360ST

24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
+2more

Color : Stainless Steel

24 Cu. Ft. Large Capacity Swing Door Bottom Freezer Refrigerator LBC24360ST
Stainless Steel

Depth : Standard Depth

Key Features

  • LG has been Evaluated by consumer Reports

  • Convenient Access.

  • Fresher is better.

  • Adaptable and Easy Access Storage.

  • Great Light.

  • Largest Capacity.*

  • 24 cu. ft. Capacity

  • Multi-Air Flow Freshness System

Read More

Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.

Features
Specifications

Features

LG has been Evaluated by consumer Reports

*Consumer Reports does not endorse products or services.

Convenient Access.

Having the fresh food section above the freezer, bottom freezer refrigerators put the food you use at eye level. The Swing Door freezer is well designed with maximum space efficiency and easy roll-out drawers.

Fresher is better.

Multi-Air Flow Freshness System is designed to maintain superior humidity and temperature levels to help keep your food fresher, longer. Digital sensors constantly monitor conditions within the refrigerator and strategically-placed vents in every section to help surround your food with cool air no matter where you put it.Fresher is better.

Adaptable and Easy Access Storage.

Full width door shelving is designed to easily accommodate items of different shapes and sizes to allow for more fresh food space. Adjustable door drawers fold-in to create more vertical storage space and accommodate tall food items.

Great Light.

LED panels in the refrigerator provide an exceptionally bright interior and saves energy over traditional lighting.

Largest Capacity.*

Get the space you need in a refrigerator that's right for your kitchen. With 24 cu. ft. of space, this largest capacity bottom mount refrigerator offers ample room to meet your storage needs.

24 cu. ft. Capacity

Multi-Air Flow Freshness System

Sophisticated Style & Design

Swing Door Freezer

Specifications

Warranty

Parts1 Year
Labor1 Year
Parts (Sealed System)7 Year
Parts (Linear Compressor)10 Year

FREEZER

Drawers2
Ice BinYes
Freezer LightPremium LED
HandleSmart Pull® Freezer Handle

REFRIGERATOR DOOR

No. of Shelves/Bin5 Total (3 Full, 1 Flip-Up + Dairy)
Door Bin ConstructionClear
Dairy CornerYes

CAPACITY

Refrigerator16.40 cu. ft.
Freezer7.70 cu. ft.
Total24.1 cu. ft.

FEATURES

Temperature Sensors6
Energy RatingENERGY STAR® Qualified
Ice SystemFactory Installed Ice Maker
Linear CompressorYes
Display TypeMembrane (Green LED)
Temperature ControlsElectronic/Digital
Door AlarmYes
Child LockYes
LoDecibel™ Quiet OperationYes
SmartDiagnosis™Yes
Daily Ice Production2.0 lbs
Ice Storage Capacity4.0 lbs
Smart Cooling® SystemYes
Multi-Air Flow CoolingYes
Hidden HingesYes

SPECIFICATIONS

Door Edge Clearance with Handle4 1/4"
Depth with Handles34 7/8"
Depth without Handles33"
Depth without Door29"
Depth (Total with Door Open)62 3/4"
Height to Top of Case68 5/8"
Height to Top of Door Hinge69 7/8"
Width32 3/4"
Door Edge Clearance without Handle2"
Installation ClearanceSides 1/8", Top 1", Back 1"
Carton Dimensions (WxHxD)34 3/8" x 70 1/2" x 36 6/8"
Weight (Unit/Carton)249 lbs. / 271 lbs.

MATERIALS AND FINISHES

Hidden HingesYes
SurfaceCoated Metal, Stainless Steel
BackFlush & Metal Cover Over Mechanical Parts
HandlesMatching Commercial Handles
Available ColorsSmooth White, Stainless Steel
Contour DoorYes

REFRIGERATOR

Folding ShelfYes
No. of Shelves1 Full / 2 Split
Cantilevered ShelvesYes
Shelf ConstructionHybrid Cantilevered Shelving
Crisper Bins2 Humidity Crispers
Glide N’ Serve®Yes
Refrigerator LightPremium LED

SUMMARY

Door TypeBottom Freezer
Total Capacity24.1 cu. ft.
Size (W x H x D)32 3/4" x 69 7/8" x 34 7/8"
ColorStainless Steel

Dimensions & Weight

Width32 in.
Height70.5 in.
Length36.75 in.
Weight249 lbs.
Carton Dimensions (WxHxD)34 3/8" x 70 1/2" x 36 6/8"
Depth with Handles34 7/8"
Depth without Handles33"
Depth without Door29"
Depth (Total with Door Open)62 3/4"
Height to Top of Case68 5/8"
Height to Top of Door Hinge69 7/8"

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width39.38 in.
Shipping Height75.5 in.
Shipping Length41.75 in.
Shipping Weight289 lbs.
Total of Shipping Weight289 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement47.98 ft³
Dimensional Weight596.46 lbs.
Total of Cubes47.98 ft³
Total of Dimensional Weight596.46 lbs.
