230 Volt Heat/Cool Room Air Conditioner - AEE18DK
230 Volt Heat/Cool Room Air Conditioner
Model: AEE18DK
230 Volt Heat/Cool Room Air Conditioner
Model: AEE18DK
Color : Light Cool Gray
Key Features
18,000 / 17,600 BTUH cooling capacity
9.7 / 9.7 EER
11,000 / 8,700 BTU (Heat)
3.0 dehumidification (pints/hr)
230/208 Volt outlet type
2 cooling / 1 fan only speeds
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
18,000 / 17,600 BTUH cooling capacity
9.7 / 9.7 EER
11,000 / 8,700 BTU (Heat)
3.0 dehumidification (pints/hr)
230/208 Volt outlet type
2 cooling / 1 fan only speeds
Certifications
California Prop 65
Specifications
Warranty
| Parts | 1 Year |
| Labor | 1 Year |
WEIGHTS & DIMENSIONS
| Min./Max. Window Opening Width (in.) | 30/41 |
| Depth to Louvers | 8.75 in |
| Minimum Window Opening Height (in.) | 18 in |
| Overall Depth | 29.90 in |
| Overall Height | 16.80 in |
| Overall Width | 25.90 in |
Dimensions & Weight
| Width | 25.9 in. |
| Height | 16.8 in. |
| Length | 29.9 in. |
| Weight | 195 lbs. |
| Approximate Shipping Weight | 168 lb |
| Min./Max. Window Opening Width (in.) | 30/41 |
| Depth to Louvers | 8.75 in |
| Minimum Window Opening Height (in.) | 18 |
| Net Weight | 195 lb |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 30.9 in. |
| Shipping Height | 21.8 in. |
| Shipping Length | 34.9 in. |
| Shipping Weight | 235 lbs. |
| Total of Shipping Weight | 235 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 7.53 ft³ |
| Dimensional Weight | 93.6 lbs. |
| Total of Cubes | 7.53 ft³ |
| Total of Dimensional Weight | 93.6 lbs. |
FEATURES
| Filter Type | One Touch Lift-Out |
| Chassis Type | Slide-Out |
| Control Panel Door | Yes |
| Plug Type | Perpendicular - 20 Amp |
| Mounting Type | EZ Mount |
| Heating - Electric - Input Watts | 3680/3030 |
| Thermostat Type | Variable Setting |
| Rotary Compressor | Yes |
| Outdoor Vent / Exhaust | Yes |
| Unit Type | Heat / Cool Unit |
| Fan Speed Selections | 2 Cooling |
| Airflow (cfm) Roomside | 460/390 |
| Fan Speed Selections | 2 Heating |
| Fan Speed Selections | 1 Fan Only |
POWER / RATINGS
| Cooling - Rated Cooling Amps AHAM | 8.3/8.9 |
| Cooling - Watts | 1860/1825 |
| Voltage (MIN) | 208 V |
| Voltage (MAX) | 230 V |
| Heating - Electric - Heater Amps | 16.0/14.6 |
APPEARANCE
| Installation | EZ Mount |
| Color Appearance | Light Cool Gray |
CAPACITY
| Cooling EER (BTUH / Watt) | 9.7/9.7 |
| Heating - Electric - BTUH - AHAM - 1R | 11,000/8,700 |
| Dehumidification (pts./hr.) | 4.2 |
| Cooling BTUH (MAX) | 18,000 Btu |
| Cooling BTUH (MIN) | 17,600 Btu |
