230 Volt Heat/Cool Room Air Conditioner - AEE12DK
230 Volt Heat/Cool Room Air Conditioner
Model: AEE12DK
230 Volt Heat/Cool Room Air Conditioner
Model: AEE12DK
Color : Light Cool Gray
Key Features
12,000 / 11,700 cooling BTU
9.8 / 9.8 EER
11,000 / 8,700 BTU (Heat)
2.0 dehumidification (pints/hr)
230/208 Volt outlet type
2 cooling / 1 fan only speeds
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
12,000 / 11,700 cooling BTU
9.8 / 9.8 EER
11,000 / 8,700 BTU (Heat)
2.0 dehumidification (pints/hr)
230/208 Volt outlet type
2 cooling / 1 fan only speeds
Certifications
California Prop 65
Specifications
Warranty
| Parts | 1 Year |
| Labor | 1 Year |
Dimensions & Weight
| Width | 22.6 in. |
| Height | 15.3 in. |
| Length | 25.8 in. |
| Weight | 96 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 27.6 in. |
| Shipping Height | 20.3 in. |
| Shipping Length | 30.8 in. |
| Shipping Weight | 136 lbs. |
| Total of Shipping Weight | 136 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 5.16 ft³ |
| Dimensional Weight | 64.18 lbs. |
| Total of Cubes | 5.16 ft³ |
| Total of Dimensional Weight | 64.18 lbs. |
FEATURES
| Louver Style | 4-Way Adjustable |
| Filter Type | Slide-Out |
| Chassis Type | Slide-Out |
| Plug Type | Perpendicular - 20 Amp |
| Mounting Type | EZ Mount |
| Heating - Electric - Input Watts | 3575/2765 |
| Thermostat Type | Variable Setting |
| Rotary Compressor | Yes |
| Unit Type | Heat / Cool Unit |
| Fan Speed Selections | 2 Cooling |
| Airflow (cfm) Roomside | 280/250 |
| Fan Speed Selections | 2 Heating |
| Fan Speed Selections | 1 Fan Only |
| Filter Type | Rigid Frame |
WEIGHTS & DIMENSIONS
| Min./Max. Window Opening Width (in.) | 27/36 |
| Depth to Louvers | 8.75 in |
| Minimum Window Opening Height (in.) | 17 in |
| Overall Depth | 25.80 in |
| Overall Height | 15.30 in |
| Overall Width | 22.60 in |
POWER / RATINGS
| Cooling - Rated Cooling Amps AHAM | 5.5/5.8 |
| Cooling - Watts | 1220/1195 |
| Voltage (MIN) | 208 V |
| Voltage (MAX) | 230 V |
| Heating - Electric - Heater Amps | 15.6/13.5 |
APPEARANCE
| Installation | EZ Mount |
| Color Appearance | Light Cool Gray |
CAPACITY
| Cooling EER (BTUH / Watt) | 9.8/9.8 |
| Heating - Electric - BTUH - AHAM - 1R | 11,000/8,700 |
| Dehumidification (pts./hr.) | 2.0 |
| Cooling BTUH (MAX) | 12,000 Btu |
| Cooling BTUH (MIN) | 11,700 Btu |
