Tempo Series 208-230V 18,000 BTU Single Zone Ductless Highwall Indoor Unit - AW18TE2VHA
Tempo Series 208-230V 18,000 BTU Single Zone Ductless Highwall Indoor Unit
Model: AW18TE2VHA
Tempo Series 208-230V 18,000 BTU Single Zone Ductless Highwall Indoor Unit
Model: AW18TE2VHA
Color : White
Key Features
Easy Install Features
Quiet Mode
Auto Louver
Turbo Mode
Blue Fin
Warm Start
Child Lock
2-Way Piping Drain
Documents
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Easy Install Features
Loaded with features installers love such as an easy installation clip and a quick mount wall bracket
Quiet Mode
Minimizes indoor noise while maintaining comfort levels
Auto Louver
A special coating that whisks away condensate water
Turbo Mode
Cools or heats the room quickly
Blue Fin
Automatically adjusts airflow upward when cooling, or downward when heating
Warm Start
Ensures the fan will not cold air during heating mode startup
Child Lock
Ensures the fan will not cold air during heating mode startup
2-Way Piping Drain
Right or left side drain configuration simplifies installation
ODU Compatibility
Compatible with ASH118CRDWA Outdoor Unit
See specification book for full heating, cooling, and system details
Specifications
WEIGHTS & DIMENSIONS
| Overall Depth | 8.875 in |
| Overall Width | 39.6875 in |
| Overall Height | 12.5 in |
| Net Weight | 26.5 lb |
| Suction O.D. Refrigerant Line | 1/2" |
| Liquid O.D. Refrigerant Line | 1/4" |
| Approximate Shipping Weight | 33.1 lb |
FEATURES
| Style | Highwall |
| Series | Tempo |
| Outdoor Model to Complete Multi Zone System | Single Zone System Only |
| Unit Type | Indoor |
| Fan Speed Selections | 5 + Auto |
| Short Description | Tempo Single Zone 18000 BTU Wall-Mounted Indoor |
| Vapor Refrigerant Line | 1/2" |
| Product Type | Single Zone |
| Fan Speed Stages | 5+ Auto |
| Outdoor Model to Complete Single Zone System | 1U18TE2VHA |
| System | 18K Tempo |
| Fan Speeds CFM | 475 |
| Indoor Sound Level | 33 |
POWER / RATINGS
| Cooling Rated Capacity BTU/Hr | 17,800 |
| Voltage/Hertz/Phase | 208-230/60/1 |
| Hertz | 60 |
| Electrical Requirements | 208/230V |
APPEARANCE
| Color Appearance | White |
Other
| Suction O.D. Refrigerant Line | 1/2" |
| Liquid O.D. Refrigerant Line | 1/4" |
Dimensions & Weight
| Width | 39.69 in. |
| Height | 12.5 in. |
| Length | 8.88 in. |
| Weight | 26.5 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 44.69 in. |
| Shipping Height | 17.5 in. |
| Shipping Length | 13.88 in. |
| Shipping Weight | 66.5 lbs. |
| Total of Shipping Weight | 66.5 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 2.55 ft³ |
| Dimensional Weight | 31.68 lbs. |
| Total of Cubes | 2.55 ft³ |
| Total of Dimensional Weight | 31.68 lbs. |
WARRANTY
| Warranty Notes | See written warranty for full details |
| Parts Warranty | 5-Year limited parts warranty |
| Labor Warranty | No Warranty |
