Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit - AW15ES2VHB

This product has been discontinued by the manufacture and is no longer available.

Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit

Model: AW15ES2VHB

Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHBAdvanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHBAdvanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHBAdvanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHBAdvanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHBAdvanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
+1more

Color : Other

Advanced Plus Series 208-230V 15,000 BTU Single-Zone Ductless Highwall Indoor Unit AW15ES2VHB
Other

Key Features

  • SmartHQ Home

  • Voice Control

  • 3-D Air Flow

  • Long Distance Air Supply

  • Warm Start

  • Quiet Mode

  • Easy Install

  • ODU Compatibility

Read More

Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.

Features
Specifications
Certifications

Features

SmartHQ Home

Monitor status, adjust temperature, and set cooling and heating schedules from anywhere using your smartphone. WiFi adapter QAWF01A required (sold separately)

Voice Control

Enjoy hands-free temperature control by connecting your ductless system to Google Assistant or Amazon Alexa. WiFi adapter QAWF01A required (sold separately)

3-D Air Flow

Designed to deliver air vertically and horizontally for even distribution and optimal comfort throughout the room

Long Distance Air Supply

Enjoy comfort made easy with a louver that adjusts airflow upward when cooling, or downward when heating

Warm Start

Get warm quickly with a fan that will not blow cold air during heating mode startup

Quiet Mode

Maintain comfort levels while minimizing indoor noise with quiet mode

Easy Install

Loaded with features installers love such as multiple line set and drain positions and a quick mount wall bracket

ODU Compatibility

Compatible with 1U15AP2VHA Outdoor Unit

See specification book for full heating, cooling, and system details

Certifications

ADA Compliant certification

ADA Compliant

Specifications

FEATURES

Outdoor Model to Complete Single Zone System1U15AP2VHA
Outdoor Model to Complete Multi Zone SystemSingle Zone System Only
Product TypeSingle Zone
Fan Speed Stages5+ Auto
StyleHighwall
Vapor Refrigerant Line1/2"
Model TypeIndoor
Indoor Sound Level34
Indoor Sound Level36
Indoor Sound Level42
Indoor Sound Level46
Indoor Sound Level48
Liquid Refrigerant Line1/4"
System15K Advanced Plus
Short DescriptionAdvanced Plus Multi Zone 15000 BTU Wall-Mounted Indoor
Fan Speed Selections5 + Auto
SeriesAdvanced Plus

CAPACITY

Max. Heating Capacity -15°F BTU/Hr10000
Max. Heating Capacity 5°F BTU/Hr16000
Max. Heating Capacity 17°F BTU/Hr17000

APPEARANCE

Color AppearanceWhite

POWER / RATINGS

Voltage/Hertz/Phase208-230/60/1
Cooling Rated Capacity BTU/Hr15,000

WARRANTY

Parts WarrantyLimited 5-Year Parts and Compressor. 10-Year Limited Parts and Compressor Warranty with Registration. See warranty documentation for complete information.

Dimensions & Weight

Width43.88 in.
Height13.25 in.
Length9.56 in.
Weight35.3 lbs.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width48.88 in.
Shipping Height18.25 in.
Shipping Length14.56 in.
Shipping Weight75.3 lbs.
Total of Shipping Weight75.3 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement3.22 ft³
Dimensional Weight39.99 lbs.
Total of Cubes3.22 ft³
Total of Dimensional Weight39.99 lbs.
