Vertical Zoneline Packaged Terminal Heat Pump - AZ75H18EAC
Vertical Zoneline Packaged Terminal Heat Pump
Model: AZ75H18EAC
Vertical Zoneline Packaged Terminal Heat Pump
Model: AZ75H18EAC
Color : Other
Key Features
17,500 / 17,200 BTU cooling capacity
15,700 / 15,500 BTU heating capacity
10.0 / 10.0 E.E.R. (BTU/Watt)
Vertical design
Freeze Sentinel protects unoccupied rooms against freeze-up
Three-way, slide-out chassis with specially designed case Makes Maintenance and Service Quick and Easy
Full corrosion treatment on outside coils and other components is standard
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
17,500 / 17,200 BTU cooling capacity
15,700 / 15,500 BTU heating capacity
10.0 / 10.0 E.E.R. (BTU/Watt)
Vertical design
Optimizes usable floor space
Freeze Sentinel protects unoccupied rooms against freeze-up
Three-way, slide-out chassis with specially designed case Makes Maintenance and Service Quick and Easy
Full corrosion treatment on outside coils and other components is standard
Certifications
California Prop 65
Specifications
FEATURES
| Remote Thermostat | RAK163 - Optional |
| Vent Control | 3-position |
| Central Desk Control Compatibility | Yes |
| Freeze Sentinel | Yes |
| Heat Pump | Yes |
| Corrosion Treated | Yes |
| Temperature Limiting | Yes |
| Power Connection Kit | RAK3152/3202/3302 |
| Fan Speed Selections | 3 Cooling |
CAPACITY
| Heating - Reverse Cycle - BTUH | 15700/15500 |
| Dehumidification (pts./hr.) | 5.0 |
| CFM Indoor Fan High | 550 |
| CFM Indoor Fan Low | 475 |
| Cooling BTUH (MAX) | 17,500 Btu |
| Cooling BTUH (MIN) | 17,200 Btu |
Dimensions & Weight
| Width | 23.13 in. |
| Height | 32.25 in. |
| Length | 23.13 in. |
| Weight | 163 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 28.13 in. |
| Shipping Height | 37.25 in. |
| Shipping Length | 28.13 in. |
| Shipping Weight | 203 lbs. |
| Total of Shipping Weight | 203 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 9.98 ft³ |
| Dimensional Weight | 124.07 lbs. |
| Total of Cubes | 9.98 ft³ |
| Total of Dimensional Weight | 124.07 lbs. |
WEIGHTS & DIMENSIONS
| Overall Depth | 23 1/8 in |
| Overall Height | 32 1/4 in |
| Overall Width | 23 1/8 in |
POWER / RATINGS
| Voltage (MAX) | 265 V |
Warranty
| Parts (Entire Appliance) | 1 Year |
| Parts (Sealed Refrigerating System) | 5 Year |
| Labor (Entire Appliance) | 1 Year |
