Elite 30-Inch Under-Cabinet Range Hood w/ Light - SPE130SS
Elite 30-Inch Under-Cabinet Range Hood w/ Light
Model: SPE130SS










Elite 30-Inch Under-Cabinet Range Hood w/ Light
Model: SPE130SS
Key Features
UL Listed
HVI Certified
Model replaced EPLEC130SS
The Captur system"s advanced blower design features a centric inlet to remove smoke and odor faster. Three-speed blower control exhausts at a powerful 600 CFM
Forward placement and smooth-flow blower wheel design ensure quiet, <0.3 Sones operation at normal speed
Tap-touch, 3-speed capacitive control features a smooth, easy-to-clean surface
Dishwasher-safe, hybrid baffle filters provide ultra-efficient grease removal with superior air flow. The filter clean reminder ensures they will always maintain a high level of capture
EZ1 brackets enable single-person installation in less than half the time of traditional methods
Documents
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
UL Listed
HVI Certified
Model replaced EPLEC130SS
The Captur system"s advanced blower design features a centric inlet to remove smoke and odor faster. Three-speed blower control exhausts at a powerful 600 CFM
Forward placement and smooth-flow blower wheel design ensure quiet, <0.3 Sones operation at normal speed
Tap-touch, 3-speed capacitive control features a smooth, easy-to-clean surface
Dishwasher-safe, hybrid baffle filters provide ultra-efficient grease removal with superior air flow. The filter clean reminder ensures they will always maintain a high level of capture
EZ1 brackets enable single-person installation in less than half the time of traditional methods
ADA compliant, remote operation is possible using a standard UL approved wall switch.
Bright, two-level ENERGY STAR LED modules – supported by a 3-year warranty – illuminate evenly and are tested in cooking environments to ensure long life without dimming. Color Temperature 3000 K
Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
Range hood is installed as hardwired or with an optional power cord kit (SHCK44; sold separately)
1-Person Installation in Half the Time
HVI Certified
UL Listed
Certifications
HVI Certified
UL Listed
Specifications
Other
| Filter Type | Hybrid Baffle |
| Heat Sentry™ | No |
| HVI Certified | Yes |
| Lighting Type | LED |
| Sound Level (Sones) | 0.3 |
| Light Bulb Wattage | 4.5 |
| Light Levels | 2 |
| Material | Steel |
| Speed Levels | 3 |
| Switch Control Type | Capacitive Touch |
| Rated Voltage | 120 |
| Country of Origin | Mexico |
| Rated Amps | 1.9 |
| Capture Efficiency | 98.5 |
| CFM | 600 |
| Diameter | 7" Round |
| Vent Type | Convertible Built-In |
| Duct Direction | Horizontal/Vertical |
| Bulb (Recommended Type) | Integrated LED Module |
| Light Color Temp | 3000 |
| Manufacturer Warranty | 1 Year, 3 Year LED module |
| Wattage | 228 |
Dimensions & Weight
| Width | 30 in. |
| Height | 9 in. |
| Length | 19.25 in. |
| Weight | - |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 14 in. |
| Shipping Length | 24.25 in. |
| Shipping Weight | - |
| Total of Shipping Weight | - |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 3.01 ft³ |
| Dimensional Weight | 37.39 lbs. |
| Total of Cubes | 3.01 ft³ |
| Total of Dimensional Weight | 37.39 lbs. |
