Glacier 36-Inch 300 Max Blower CFM 5 Sones Range Hood - BCSD136BC
Glacier 36-Inch 300 Max Blower CFM 5 Sones Range Hood
Model: BCSD136BC
Glacier 36-Inch 300 Max Blower CFM 5 Sones Range Hood
Model: BCSD136BC
Color : Bisque
Key Features
Clean lines and contemporary style in an under-cabinet convertible range hood that will complement nearly any kitchen
Hidden rocker switches adjust fan speed and lighting levels
Captur system and 300 Max Blower CFM is 97.4% efficient in removal of smoke and odor from cooking
Convertible to accommodate either top or rear venting applications or non-ducted operation using charcoal filters, which are sold separately (Filter Model HFP36)
2 dishwasher-safe open mesh filters feature advanced high-flow technology to grab more airborne grease
2-halogen bulbs (purchase separately) provide warm light over the cooking surface, adjustable to high or low levels
1-year limited manufacturer’s warranty
EZ1 system enables easy single-person installation in up to half the time of traditional methods
Description
This under-cabinet convertible range hood features a clean, contemporary shape to complement nearly any kitchen design. Equipped with the exclusive Broan Captur™ system, which combines advanced blower design with new filter technology, this 300 Max Blower CFM-rated hood provides 97.4% removal of smoke and odor to protect your home and family from airborne pollutants caused from cooking. The quiet-running Glacier is also designed with smooth flow technology, which streamlines the path of air for improved efficiency and noise reduction. Easy-flip rocker switches control the 2 fan speeds and halogen lighting system. Using the included EZ1® system, Glacier can easily be installed by one person in up to half the time of a standard install.
Documents
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Clean lines and contemporary style in an under-cabinet convertible range hood that will complement nearly any kitchen
Hidden rocker switches adjust fan speed and lighting levels
Captur system and 300 Max Blower CFM is 97.4% efficient in removal of smoke and odor from cooking
Convertible to accommodate either top or rear venting applications or non-ducted operation using charcoal filters, which are sold separately (Filter Model HFP36)
2 dishwasher-safe open mesh filters feature advanced high-flow technology to grab more airborne grease
2-halogen bulbs (purchase separately) provide warm light over the cooking surface, adjustable to high or low levels
1-year limited manufacturer’s warranty
EZ1 system enables easy single-person installation in up to half the time of traditional methods
Range hood is installed as hardwired or with an optional power cord kit (SHCK44; sold separately)
Specifications
Warranty
| Parts | 1 Year |
| Labor | 1 Year |
Other
| Filter Type | Open Mesh |
| Heat Sentry™ | No |
| HVI Certified | Yes |
| Lighting Type | Halogen |
| Sound Level (Sones) | 1.5 |
| Light Bulb Wattage | 50 |
| Light Levels | 2 |
| Material | Steel |
| Switch Control Type | Rocker |
| Rated Voltage | 120 |
| Country of Origin | Mexico |
| Rated Amps | 1.4 |
| Capture Efficiency | 97.4 |
| CFM | 300 Max |
| Diameter | 7" Round |
| Vent Type | Convertible Built-In |
| Duct Direction | Horizontal/Vertical |
| Bulb (Recommended Type) | GU10 MR16 |
| Manufacturer Warranty | 1 Year |
| Wattage | 168 |
Dimensions & Weight
| Width | 36 in. |
| Height | 6 in. |
| Length | 19.63 in. |
| Weight | - |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 2.45 ft³ |
| Dimensional Weight | 30.5 lbs. |
| Total of Cubes | 2.45 ft³ |
| Total of Dimensional Weight | 30.5 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Shipping Width | 24 in. |
| Shipping Depth | 39 in. |
| Shipping Height | 8 in. |
| Shipping Weight | 23 lb. |
