NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM - AHSA130SS

This product has been discontinued by the manufacture and is no longer available.

NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM

Model: AHSA130SS

NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SSNuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SSNuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SSNuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SSNuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS

Color : Stainless Steel

NuTone 30-Inch Convertible Under-Cabinet Range Hood, 250 CFM AHSA130SS
Stainless Steel

Key Features

  • UL Listed

  • HVI Certified

  • Convertible range hood can be installed as venting or non-venting to fit a variety of installation needs

  • Hidden rocker switches adjust fan speed and lighting levels

  • Quiet operation at both high and low speeds

  • Captur exhaust system and 250 CFM blower is up to 97.4% efficient in removal of smoke and odor from cooking

  • Convertible to accommodate either top or rear venting applications, or non-ducted operation using charcoal filters, which are sold separately (Filter Model S97020464)

  • Dishwasher-safe open mesh filter features high-flow technology to grab more airborne grease

Read More

Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.

Features
Specifications
Certifications

Features

UL Listed

HVI Certified

Convertible range hood can be installed as venting or non-venting to fit a variety of installation needs

Hidden rocker switches adjust fan speed and lighting levels

Quiet operation at both high and low speeds

Captur exhaust system and 250 CFM blower is up to 97.4% efficient in removal of smoke and odor from cooking

Convertible to accommodate either top or rear venting applications, or non-ducted operation using charcoal filters, which are sold separately (Filter Model S97020464)

Dishwasher-safe open mesh filter features high-flow technology to grab more airborne grease

2 halogen bulbs, included, provide warm light over the cook surface, adjustable to high or low levels

Hidden louvers on top of hood exhaust away from cabinetry

Open-bottom, under-cabinet convertible range hood features stylish, curved design and hidden controls to blend neatly into any kitchen

1-year limited manufacturer’s warranty

Non-duct capable with use of charcoal filters (NuTone model HPF1 sold separately)

Range hood is installed as hardwired or with an optional power cord kit (SHCK44; sold separately)

HVI Certified

UL Listed

Certifications

UL Listed certification

UL Listed

Specifications

Other

Filter TypeOpen Mesh
Heat Sentry™No
HVI CertifiedYes
Lighting TypeHalogen
Sound Level (Sones)1.5
Light Bulb Wattage50
Light Levels2
MaterialSteel
Switch Control TypeRocker
Rated Voltage120
Country of OriginMexico
Rated Amps1.4
Capture Efficiency97.4
CFM250
Diameter7" Round
Vent TypeConvertible Built-In
Duct DirectionHorizontal/Vertical
Bulb (Recommended Type)GU10 MR16
Manufacturer Warranty1 year

Dimensions & Weight

Width30 in.
Height6 in.
Length19.63 in.
Weight-

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width35 in.
Shipping Height11 in.
Shipping Length24.63 in.
Shipping Weight-
Total of Shipping Weight-
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement2.04 ft³
Dimensional Weight25.41 lbs.
Total of Cubes2.04 ft³
Total of Dimensional Weight25.41 lbs.
