36" Telescopic Downdraft System - JVB98SHSS
36" Telescopic Downdraft System
Model: JVB98SHSS
36" Telescopic Downdraft System
Model: JVB98SHSS
Color : Stainless Steel
Key Features
36-inch telescopic downdraft system
390 CFM performance with Variable Speed fan control
Raises to 8-1/2" over cooktop surface
Retracts when not in use
3-1/4" x 10" rectangular duct
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
36-inch telescopic downdraft system
390 CFM performance with Variable Speed fan control
Raises to 8-1/2" over cooktop surface
Retracts when not in use
3-1/4" x 10" rectangular duct
Certifications
California Prop 65
Specifications
WEIGHTS & DIMENSIONS
| Cabinet Width | 36 in |
| Overall Height | 27 in |
| Overall Width | 36 in |
| Net Weight | 61 lb |
| Approximate Shipping Weight | 76 lb |
| Overall Depth | 2 1/4 in |
FEATURES
| Fan Speed Control | Variable |
| Separate Remote Raise/Lower Switch | Yes |
| Downdraft Exhaust (CFM) | 390 |
| Exhaust Options | 3-1/4" x 10" Rectangular Duct |
| Telescopic Assembly | Black / Stainless Steel |
| Cover Plate | Stainless Steel |
POWER / RATINGS
| Amp Rating at 120V | 4.0 |
APPEARANCE
| Color Appearance | Stainless Steel |
Dimensions & Weight
| Width | 36 in. |
| Height | 27 in. |
| Length | 2.25 in. |
| Weight | 61 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 41 in. |
| Shipping Height | 32 in. |
| Shipping Length | 7.25 in. |
| Shipping Weight | 101 lbs. |
| Total of Shipping Weight | 101 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 1.27 ft³ |
| Dimensional Weight | 15.73 lbs. |
| Total of Cubes | 1.27 ft³ |
| Total of Dimensional Weight | 15.73 lbs. |
