30" Telescopic Downdraft System - JVB37HCC
30" Telescopic Downdraft System
Model: JVB37HCC
30" Telescopic Downdraft System
Model: JVB37HCC
Color : Bisque on Bisque
Replaced By
Key Features
Telescopic downdraft hood
500 CFM
Variable speed fan control
Removable grease filter
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Telescopic downdraft hood
Hood raises over cooktop surface and retracts when not in use
500 CFM
Powerful 500 CFM performance removes smoke and vapors from the cooking area
Variable speed fan control
The powerful variable speed exhaust system effectively pulls smoke and vapors out of the kitchen
Removable grease filter
Durable filters can be removed for easy cleaning and maintenance
Certifications
California Prop 65
Specifications
WEIGHTS & DIMENSIONS
| Cabinet Width | 30 in |
| Overall Height | 27 in |
| Overall Width | 30 in |
| Overall Depth | 2 1/4 in |
FEATURES
| Fan Speed Control | Variable Speed With Slide Control |
| Optional Blower Mount Capabilities | Yes |
| Downdraft Exhaust (CFM) | 390 |
| Exhaust Options | Minimum 6" Round Duct Capability |
| Telescopic Assembly | Black |
| Cover Plate | Bisque |
| Removable Grease Filter(s) | Yes |
| Exhaust Options | 3-1/4" x 10" Rectangular Duct |
POWER / RATINGS
| Amp Rating at 120V | 4.0 |
APPEARANCE
| Color Appearance | Bisque on Bisque |
Dimensions & Weight
| Width | 30 in. |
| Height | 27 in. |
| Length | 2.25 in. |
| Weight | 57 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 32 in. |
| Shipping Length | 7.25 in. |
| Shipping Weight | 97 lbs. |
| Total of Shipping Weight | 97 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 1.05 ft³ |
| Dimensional Weight | 13.11 lbs. |
| Total of Cubes | 1.05 ft³ |
| Total of Dimensional Weight | 13.11 lbs. |
