Dual Fuel Range, 48", 5 Burners with Griddle - RDV2485GDNN
Dual Fuel Range, 48", 5 Burners with Griddle
Model: RDV2485GDNN
Dual Fuel Range, 48", 5 Burners with Griddle
Model: RDV2485GDNN
Rebate AvailableColor : Other
Replaced By
48" Series 9 Professional Dual Fuel 5 Burner with Griddle Self-Cleaning Range, Natural Gas
Model: RDV3485GDN
Current Rebates
Key Features
Cooktop power
Total control
Consistent broiling
Easy to clean
Instant visibility
Cooking flexibility
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Cooktop power
Total control
Consistent broiling
Easy to clean
Instant visibility
Cooking flexibility
Specifications
Gas requirements
| Fitting and pipe | ½ NPT, min. â…" Ø flex line |
Main oven features
| Capacity total (AHAM) | 4.8cu ft |
| Capacity usable (AHAM) | 3.8cu ft |
| Shelf positions | 5 |
Main oven functions
| Number of main oven functions | 6 |
| Bake | 4600W |
| Broil | 4000W |
Oven performance
| Main oven - True convection power | 2500W |
Power requirements
| Supply frequency | 60 |
| Supply voltage | 120 - 240 |
Oven features
| Full extension telescopic sliding shelves | 3 |
| True convection | 2500W |
Rangetop features
| Sealed Dual Flow Burners™ | 5 |
| Simmer on all burners | 140°F |
| Vent trim included | Flat vent trim |
Rangetop Performance
| Power front left | 18500BTU |
| Max burner power | 23500BTU |
| Power back left | 18500BTU |
| Power back right | 18500BTU |
| Power centre | 23500BTU |
| Power griddle | 24000BTU |
| Total cooktop power | 121500BTU |
| Power front right | 18500BTU |
Secondary oven features
| Capacity usable (AHAM) | 1.8cu ft |
| Capacity total (AHAM) | 2.1cu ft |
| Shelf positions | 5 |
Secondary oven functions
| Bake | 2450W |
| Broil | 3600W |
| Number of secondary oven functions | 3 |
Warranty
| Parts | 2 Year |
| Labor | 2 Year |
Other
| Fitting and pipe | ½ NPT, min. â…" Ø flex line |
| Capacity total (AHAM) | 4.8cu ft |
| Capacity usable (AHAM) | 3.8cu ft |
| Shelf positions | 5 |
| Bake | 4600W |
| Broil | 4000W |
| Number of main oven functions | 6 |
| Full extension telescopic sliding shelves | 3 |
| True convection | 2500W |
| Supply frequency | 60 |
| Supply voltage | 120 - 240 |
| Simmer on all burners | 140°F |
| Vent trim included | Flat vent trim |
| Max burner power | 23500BTU |
| Power back left | 18500BTU |
| Power griddle | 24000BTU |
| Total cooktop power | 121500BTU |
| Capacity total (AHAM) | 2.1cu ft |
| Capacity usable (AHAM) | 1.8cu ft |
| Bake | 2450W |
| Broil | 3600W |
Dimensions & Weight
| Width | 47 in. |
| Height | 35 in. |
| Length | 29 in. |
| Weight | - |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 52 in. |
| Shipping Height | 40 in. |
| Shipping Length | 34 in. |
| Shipping Weight | - |
| Total of Shipping Weight | - |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 27.61 ft³ |
| Dimensional Weight | 343.2 lbs. |
| Total of Cubes | 27.61 ft³ |
| Total of Dimensional Weight | 343.2 lbs. |
