30" Free-Standing Gas Range - RGB745BEHWH
30" Free-Standing Gas Range
Model: RGB745BEHWH
30" Free-Standing Gas Range
Model: RGB745BEHWH
Color : White
Replaced By
Key Features
Self-clean oven
Extra-large oven capacity
Sealed cooktop burners
Performance plus burner
Simmer setting
All purpose burners
EasySet III controls
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Self-clean oven
Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
Extra-large oven capacity
Enough room to cook an entire meal at once
Sealed cooktop burners
Burner elements are sealed to the cooktop to keep foods and liquid contained on the cooktop, making cleaning painless
Performance plus burner
This 12,000 BTU burner element provides the high heat ideal for frying or sautéing and fast heat-up
Simmer setting
Simmer setting allows for low, even heat distribution for delicate foods and sauces
All purpose burners
All-purpose burner delivers two levels of BTU output to accommodate virtually all your cooking needs
EasySet III controls
Glass one-touch control panel makes everyday operation and cleaning incredibly easy
Certifications
California Prop 65
Specifications
WEIGHTS & DIMENSIONS
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 18-1/2 x 19 |
| Overall Width | 30 in |
| Overall Depth | 26.25 in |
| Overall Height | 46.5 in |
| Net Weight | 190 lb |
| Cabinet Width | 30 in |
| Approximate Shipping Weight | 210 lb |
FEATURES
| Configuration | Range with Storage Drawer |
| Ignition System | Electronic |
| Interior Oven Light | Yes |
| Fuel Type | Natural Gas |
| Oven Control Features | In-Oven Broiling |
| Cooktop Burner Type | Sealed |
| Oven Rack Features | Embossed Rack Positions |
| Oven Cleaning Type | Self-Clean |
| All-Purpose Burners | (2) 9,500/850 BTU |
| Performance Plus Burner | (1) 12,000/1,000 BTU |
| Cooktop Burner Grate Material | Heavy Steel |
| Valves (Degree of Turn) | 270 |
| Backguard | Scratch-Resistant |
| Simmer Burner | (1) 5,000/600 BTU |
| Cooktop Surface | Porcelain-Enamel |
| Oven Rack Positions (Single or Upper/Lower) | 6 |
| Leveling System | 4 Leveling Legs |
| Control Type | EasySet III |
| One-Piece Drip Pans | Black Porcelain-Enameled |
APPEARANCE
| Cooktop Burner Grate Color | Black |
| Oven Door Features | Oven Window |
| Handle | Designer Style |
| Frameless Oven Door(s) | Black Glass |
| Color Appearance | White |
CAPACITY
| Unit Capacity | Extra Large Oven |
ACCESSORIES
| LP Conversion Kit | Included |
POWER / RATINGS
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 12.0; (2) 9.5; (1) 5.0 |
| Volts/Hertz/Amps | 120V; 60Hz; 5A |
| Top Burner BTU Rating - LP (000's BTU's) | (1) 9.5; (1) 3.5; (2) 7.0 |
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Bake / 13.5 Broiler |
| Bake/Broiler BTU Rating - LP (000's BTU's) | 16.0 Bake / 12.0 Broiler |
Dimensions & Weight
| Width | 30 in. |
| Height | 46.5 in. |
| Length | 26.25 in. |
| Weight | 190 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 51.5 in. |
| Shipping Length | 31.25 in. |
| Shipping Weight | 230 lbs. |
| Total of Shipping Weight | 230 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 21.19 ft³ |
| Dimensional Weight | 263.44 lbs. |
| Total of Cubes | 21.19 ft³ |
| Total of Dimensional Weight | 263.44 lbs. |
Warranty
| Labor (Entire Appliance) | 1 Year |
| Parts (Entire Appliance) | 1 Year |
