Kitchenaid® Over-the-range Microwave With Flush Built-in Design - KMMF330PBS
Kitchenaid® Over-the-range Microwave With Flush Built-in Design
Model: KMMF330PBS
Kitchenaid® Over-the-range Microwave With Flush Built-in Design
Model: KMMF330PBS
Color : Black Stainless
Key Features
Sensor Functions
1.1 Cu. Ft. Capacity
Turntable-free design
Description
*when installed in standard cabinet depth of 12 ¾”.
Documents
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Sensor Functions
Removes the guesswork of cooking times by automatically adjusting the time needed to cook or reheat your food on select presets.
1.1 Cu. Ft. Capacity
Provides room to heat multiple dishes at once, complementing your oven as an additional cooking space.
Turntable-free design
Skip the cramming and crowding—a turntable-free design allows corner-to-corner cooking so you can prepare multiple dishes at once for more cooking and quick cleanup.
Specifications
Controls
| Control Location | Hidden |
| Control Type | Electronic Touch |
| Display Color | White |
| Electronic Display Type | LCD |
| Number of Keypads | 31 |
| Convenience Cooking Controls | Yes |
| Number of Power Levels | 10 |
| Number of Sensor Control Keypads | 8 |
| One Touch Cooking | Yes |
| Microwave Selections | Add 30 Seconds, Add A Minute, Auto Cook, Beverage, Cook Power, Cook Time, Cook/Start, Defrost, Dinner Plate, End of Cycle Signal, Fresh Vegetable, Frozen Entree, Keep Warm, Off/Cancel, Pizza, |
| Number of Vent Speeds | 3 |
Microwave Details
| Grill | No |
| Microwave Interior Light | LED |
| Door Release | Touch to Open |
| Sensor Cooking | Yes |
Certifications
| UL | Yes |
Electrical
| Amps | 15 |
| Hz | 60 |
| Power Cord Included | Yes |
| Volts | 120 |
| Watts | 1 |
Dimensions & Weight
| Width | 32.7 in. |
| Height | 14.75 in. |
| Length | 21.75 in. |
| Weight | 65 lbs. |
| Carton Depth | 21 3/4 |
| Carton Height | 14 3/4 |
| Carton Width | 32 3/4 |
| Depth Closed Excluding Handles | 12 3/4 |
| Depth Closed Including Handles | 12 3/4 |
| Depth Excluding Doors | 12 3/4 |
| Gross Weight | 64.6 lbs. |
| Net Weight | 62.0 |
| Cutout Depth Max(IN,inches) | 13.0000 |
| Cutout Depth Min(IN,inches) | 12.7500 |
| Cutout Height(IN,inches) | 18.0000 |
| Cutout Width Min(IN,inches) | 30.0000 |
| Depth Closed Excluding Handles(IN,inches) | 12.7500 |
| Depth Closed Including Handles(IN,inches) | 12.7500 |
| Depth Excluding Doors(IN,inches) | 12.7500 |
| Depth With Door Open 90 Degree(IN,inches) | 41.5000 |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 22.88 in. |
| Shipping Length | 17.75 in. |
| Shipping Weight | 105 lbs. |
| Total of Shipping Weight | 105 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 3.96 ft³ |
| Dimensional Weight | 49.19 lbs. |
| Total of Cubes | 3.96 ft³ |
| Total of Dimensional Weight | 49.19 lbs. |
Details
| Cavity Finish | Powder Coat |
| Clock | Yes |
| Door Opening Direction | Left |
| Grill | No |
| Microwave Type | Over-the-Range |
| Work Surface Light | LED |
| Blower Type | Centrifugal |
| Door Release | Touch to Open |
| Microwave Interior Light | LED |
Ventilation Details
| Blower Type | Centrifugal |
| CFM Motor Class | 400 |
| Duct Direction | Vertical or Horizontal |
| Duct Type | Rectangular |
| Fan Speed Indicator | Yes |
| Filters | Charcoal Recirculating Filter |
| Night Light | Yes |
| Vent Fan Location | Back |
| Ventilation Type | Updraft |
| Venting | Exterior or Recirculating |
| Duct Outlet Size | 3.25 W x 10 H in |
Oven Cavity Details
| Convection | No |
| Cooking Power | 1,000 w |
Exterior Details
| Cabinet Color | Black |
| Door Opening Direction | Left |
| Handle Color | No Handle |
Dimensions
| Cutout Depth Max | 13 in |
| Interior Depth | 11 in |
| Net Weight | 62 lbs |
| Capacity | 1.1 cu. ft. |
| Width | 30 in |
| Cutout Depth Min | 12.75 in |
| Depth | 12.75 in |
| Depth Closed Excluding Handles | 12.75 in |
| Depth Closed Including Handles | 12.75 in |
| Depth Excluding Doors | 12.75 in |
| Depth With Door Open 90 Degree | 41.5 in |
| Gross Weight | 64.6 lbs |
| Height | 17.875 in |
| Interior Height | 9.125 in |
| Interior Width | 18.125 in |
Capacity
| Volume | 6.526 Cu.Ft. |
