Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven - CVM517P4MW2

This product has been discontinued by the manufacture and is no longer available.

Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven

Model: CVM517P4MW2

Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
+2more

Product Video

Cafe Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven Matte White CVM517P4MW2 Picture
5 Videos

Color : Matte White

Café 1.7 Cu. Ft. Convection Over-the-range Microwave Oven CVM517P4MW2
Matte White

Key Features

  • Delicious results in no time at all

  • A microwave that’s as versatile as you are

  • Brighten up the room

  • Like a breath of fresh air

  • Cook more at once

  • Cook your way with just one touch of a button

  • More room for more food

  • Create a streamlined cooking experience

Read More

Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.

Features
Specifications
Certifications

Features

Delicious results in no time at all

Enjoy oven-quality results in mere minutes with a fast cook setting that combines convection and microwave cooking technology

A microwave that’s as versatile as you are

Achieve crisp, golden brown results with a convection cooking setting and a special rack that allows air to circulate around foods for even heat distribution

Brighten up the room

Illuminate the entire cooking surface with crisp, clear LED cooktop lighting that can also save on energy costs

Like a breath of fresh air

Keep your kitchen ready for guests with a three-speed, 300-CFM venting system that removes smoke, grease, odors and moisture

Cook more at once

Prepare plenty of food with full-width removable oven rack that allow for multi-level cooking at the same time

Cook your way with just one touch of a button

Enjoy the convenience of one-touch cooking with My Cycle, a custom cycle that remembers the exact time and temperature settings of your favorite foods

More room for more food

Entertaining unexpected guests is easy with the 1.7 cu. ft. capacity that helps prepare a large amount of food quickly

Create a streamlined cooking experience

Simplify your cooking steps by using Chef Connect to automatically activate vents and surface lights when a range element is turned on, as well as sync your microwave and range clocks

A simple and smart addition to your culinary repertoire

Fresh vegetables and rice are perfectly prepared with a steam cook button that simplifies the entire process

Say goodbye to guesswork

Enjoy consistently delicious results with sensor cooking controls that automatically adjust the time and power

Sparkling clean with just a wipe

Focus on the food and forget the mess knowing that the stainless steel interior with steam clean lets you swiftly wipe away spills and splatters

Certifications

California Prop 65 certification

California Prop 65

Specifications

WEIGHTS & DIMENSIONS

Overall Height16.3125 in
Approximate Shipping Weight95 lb
Cabinet Width30 in
Net Weight85 lb
Overall Width29.875 in
Cavity (W x H x D)21.63 x 9.75 x 14.1
Cutout Depth (in)12
Cutout Dimensions (w x h x d) (in.)30 x 17.5 x 12
Cutout Height (in)17.5
Cutout Width (in)30
Depth with Door Open29.625 in
Exterior Height (Front)15.75 in
Exterior Height (Rear)16.5 in

FEATURES

Display TypeLED
Cooking ModesMicrowave
Electronic Digital Display with ClockYes (LED)
Control FeaturesVent Fan
Microwave Sensor Cooking ControlsSteam Cook
Rack Type2 Fixed Positions
Display Screen Size (Diagonal Length)3.13
Product TypeOver-the-range Microwave
Convection Cooking ControlsRoast
StyleOver-The-Range
Turntable On / OffYes
Microwave Watts (IEC-705)950 W
Power Levels10
Control TypeGlass Touch
Display On/OffYes
Microwave Oven InteriorStainless Steel
Cooktop LightingLED
Exhaust Fan300-CFM
TurntableGlass
Cooking TechnologyMicrowave/Convection
Interior Oven LightHalogen
Cooking ModesFast Cook
Microwave Sensor Cooking ControlsCook (5 Foods)
Control FeaturesCancel/Off
Rack Type1 Square Rack
Convection Cooking ControlsFast Cook
Control FeaturesStart/Pause
Control FeaturesPower Level
Control FeaturesAdd 30 Seconds
Control FeaturesCook Time
Control FeaturesSteam Clean
Control FeaturesChef Connect On/Off
Control FeaturesTimer On/Off
Control FeaturesTurntable On/Off
Control FeaturesMute On/Off
Control FeaturesSettings
Control FeaturesSurface Light
Control FeaturesMy Cycle
Control TypeDial
Convection Cooking ControlsBake
Cooking ModesConvection Bake
Cooktop LightingHigh/Low/Off
Exhaust Fan3-Speed
Microwave Sensor Cooking ControlsPopcorn
Microwave Sensor Cooking ControlsReheat
Microwave Sensor Cooking ControlsBeverage
Microwave Sensor Cooking ControlsDefrost: Weight/Time
Rack Type1 Round Rack
Turntable Size13.6

ACCESSORIES

Optional Side Filler Panel Kit36" Filler Kit -- JX36BW1
Recirculating Charcoal Filter KitJX81D or WB02X35607 (included)
Optional KitsCXOTRHKPMSS Brushed Stainless
Optional KitsCXOTRHKPMBT Brushed Black
Optional KitsCXOTRHKPMCU Brushed Copper
Optional KitsCXOTRHKPMBZ Brushed Bronze
Optional KitsCXOTRHKPMCG Brushed Brass
Optional KitsCXOTRHKPMFB Flat Black
Optional Kits15" Bump Out Kit - JX15BUMPWW

APPEARANCE

Case ColorGraphite Gray
Handle ColorBrushed Bronze
Door ColorMatte White
Color AppearanceMatte White

POWER / RATINGS

Input Volts/Hertz120/60
Electrical Input - 120V Watts1700

CAPACITY

Vent CFM300
Exhaust Capacity300 ft3/min
Total Capacity (cubic feet)1.70 cu ft

ECONOMICAL / QUIET

Venting TypeExternally Vented

Other

Cavity (W x H x D)21-5/8 x 9-3/4 x 14-1/8

Dimensions & Weight

Width29.88 in.
Height16.31 in.
Length17.94 in.
Weight85 lbs.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width34.88 in.
Shipping Height21.31 in.
Shipping Length22.94 in.
Shipping Weight95 lbs.
Total of Shipping Weight95 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement5.06 ft³
Dimensional Weight62.89 lbs.
Total of Cubes5.06 ft³
Total of Dimensional Weight62.89 lbs.

Warranty

Labor (Entire Appliance)1 Year
Parts (Magnetron Tube)5 Year
Parts (Entire Appliance)1 Year
