Lustre 30" Induction Cooktop - JIC4530KS

JennAirJennAir brand logo
This product is discontinued and has been replaced by the model below.

Lustre 30" Induction Cooktop

Model: JIC4530KS

Lustre 30" Induction Cooktop JIC4530KSLustre 30" Induction Cooktop JIC4530KS
Lustre 30" Induction Cooktop JIC4530KS
Lustre 30" Induction Cooktop JIC4530KS

Color : Stainless Steel

Lustre 30" Induction Cooktop JIC4530KS
Stainless Steel
Replaced By

36" Lustre Smart Induction Cooktop With Temperature-controlled Cooking

Model: JICT736SS

Product - JICT736SS
View Product

Key Features

  • Magnetic Induction

  • Traditional Installation

  • Versatile Installation

  • Emotive Controls

  • Assisted Cooking

  • Lustre Brushed Metal Design

Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.

Features
Specifications

Features

Magnetic Induction

Magnetism with a pulse. A surface that heats only the induction cookware for fierce, flexible power.

Traditional Installation

Sleek and with a beveled edge, this JennAir® cooktop installs and sits higher than 3mm on any level countertop, including an island or peninsula.

Versatile Installation

Install without limits. This JennAir® cooktop can be installed true flush or semi-flush at 3mm above any level countertop, including an island or peninsula.

Emotive Controls

Striking and inviting controls with LED lighting unleash performance at your touch.

Assisted Cooking

Assisted Cooking cycles calculate and set the ideal cooking time and temperature for common foods like casseroles, meat, fish, vegetables, pizza and some baked goods.

Lustre Brushed Metal Design

Blur the lines of temptation with tight corners of lustrous brushed metal that will leave you reeling.

Specifications

Warranty

Parts2 Year
Labor2 Year

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement3.82 ft³
Dimensional Weight47.45 lbs.
Total of Cubes3.82 ft³
Total of Dimensional Weight47.45 lbs.

Dimensions & Weight

Width34.15 in.
Height7.64 in.
Length25.28 in.
Weight59 lbs.
Carton Depth25 5/16
Carton Height7 11/16
Carton Width34 3/16
Gross Weight59
Net Weight46.0
Cutout Depth Min(IN,inches)20.4700
Cutout Width Min(IN,inches)29.4800
Depth(IN,inches)22.3125
Maximum Height(IN,inches)4.0000
Minimum Height(IN,inches)3.6667
Net Weight(LB,pounds)46
Carton Depth(IN,inches)25.3125
Carton Height(IN,inches)7.6875
Carton Width(IN,inches)34.1875
Gross Weight(LB,pounds)59
Cutout Depth Min20.47
Cutout Width Min29.48
carton depth25.28
carton height7.64
carton width34.15
gross weight59
net weight46

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width34.19 in.
Shipping Height7.69 in.
Shipping Length30.28 in.
Shipping Weight99 lbs.
Total of Shipping Weight99 lbs.
SourceCalculation

Cooktop Details

Cooktop Surface MaterialGlass
Digital DisplayYes
Heating Element On Indicator LightYes
Hot Surface Indicator LightYes
Ignition TypeElectronic Button
Installs Over Built-In OvenYes
Combination Match with OvenJjw2424, Jjw2427, Jjw2430, Jjw3430, Jmc6224 (us Only)
Cooktop Surface ColorBlack On Stainless
Griddle IncludedN/a

Details

Cooktop ConfigurationAll Burners
Design ExpressionLustre Stainless
Digital DisplayYes
Fuel TypeElectric Induction
Installs Over Built-In OvenYes
LP ConvertibleNo
Power Outage CompatibleNo

Ventilation Details

Downdraft VentNo
Ventilation TypeUpdraft

Controls

Control TypeElectronic Tap Touch
Control LocationFront

Element/Burner Details

Automatic Pan DetectionYes
Automatic Pan Size AdjustmentYes
Cooktop Element StyleInduction
Cooktop TypeStandard
Center Front Element-Burner Size11in.
Center Front Element-Burner TypeDual
Left Front Element-Burner Size6in.
Left Front Element-Burner TypeRound
Left Rear Element-Burner TypeRound
Number of Cooking Element-Burners5
Left Rear Element-Burner Size7in.
Right Front Element-Burner Size6in.
Power BoostYes
Right Rear Element-Burner Size7in.
Right Front Element-Burner TypeRound
Center Front Element-Burner Power2100w/ 4000w Boost
Left Front Element-Burner Power1200w/1800w Boost
Left Rear Element-Burner Power1800w/2150w Boost
Right Front Element-Burner Power1200w/ 1800w Boost
Right Rear Element-Burner Power1800w/ 2150w Boost

Electrical

Hz60
208V CompatibleYes
Amps40
Power Cord IncludedNo
Volts240
Watts10

Dimensions

Common Size30 In
Gross Weight59 Lbs
Height4 In
Maximum Height4 In
Net Weight46 Lbs
Cutout Depth Min20.47 In
Depth21.3 In
Minimum Height3.6667 In
Width25.6 In

Certifications

Prop 65California Residents Only - Warning: Cancer And Reproductive Harm - Www.p65warnings.ca.gov.
