Series Built-In Downdraft Gas Modular Cooktop - PGP990DEFBB
Series Built-In Downdraft Gas Modular Cooktop
Model: PGP990DEFBB
Series Built-In Downdraft Gas Modular Cooktop
Model: PGP990DEFBB
Color : Black
Key Features
Modular cooktop options
Two-burner gas module
Downdraft exhaust
Sealed cooktop burners
Description
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Modular cooktop options
Accepts optional Select-Top modules (left bay)
Two-burner gas module
Shipped with unit (right bay), offers multiple temperature settings
Downdraft exhaust
Powerful exhaust system effectively pulls smoke and steam out of the kitchen
Sealed cooktop burners
Keep spillover contained on cooktop, making cleaning quick and easy
Certifications
ADA Compliant
California Prop 65
Specifications
WEIGHTS & DIMENSIONS
| Cabinet Width | 30 in |
| Overall Width | 30 in |
| Approximate Shipping Weight | 74 lb |
| Net Weight | 64 lb |
| Overall Depth | 21 3/4 in |
| Overall Height | 18 1/2 in |
FEATURES
| Removable Grease Filter(s) | Yes |
| Dishwasher Safe Knobs | Yes |
| Mix or Match Component Capability | Yes |
| Cooktop Burner Type | 2 Sealed |
| Valves (Degree of Turn) | 270 |
| Optional Blower Mount Capabilities | Back or Straight Down |
| Burner - Right Rear | 10,000 BTU |
| Variable Speed Fan | 3 Speeds - Hi/Med/Low |
| Burner - Right Front | 10,000 BTU |
| Accepts Modules | Left and Right Side |
| Fuel Type | Natural Gas |
| Gas Grill Module (sold separately) | JXGG90L (left side only) |
| Griddle Module (sold separately) | JXGL90L (left side only, requires grill module (JXGG90L) to operate) |
| Control Location | Upfront |
| Component Style | Downdraft Vent |
| Ignition System | Electronic |
| Cooktop Surface | Deep Porcelain-Enamel |
| Two Burner Gas Module (right side included) | JXGB91B (left side sold separately) |
| Control Type | Infinite Heat Rotary |
| Space Required Below Cooktop | 6 in |
| CFM/ Sones Rating | 390/ 6.5 (High Speed) |
| Cooktop Burner Grate Features | Matte Black |
| Configuration | Dual Modular - Both sides accept optional modules |
| Cooktop Burner Grate Features | Continuous Grates |
| Cooktop Burner Grate Features | Dishwasher Safe |
POWER / RATINGS
| Burner BTU Ratings (000's/BTU) - LP Gas | (1) 9.1 |
| Griddle BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
| Grill BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
| Grill BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
| Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 10.0 |
| Griddle BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
ACCESSORIES
| LP Conversion Kit | Included |
APPEARANCE
| Color Appearance | Black |
| Cooktop Burner Grate Color | Black Gloss |
| Control Panel Color | Black |
Dimensions & Weight
| Width | 30 in. |
| Height | 18.5 in. |
| Length | 21.75 in. |
| Weight | 64 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 23.5 in. |
| Shipping Length | 26.75 in. |
| Shipping Weight | 104 lbs. |
| Total of Shipping Weight | 104 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 6.99 ft³ |
| Dimensional Weight | 86.84 lbs. |
| Total of Cubes | 6.99 ft³ |
| Total of Dimensional Weight | 86.84 lbs. |
