Gas Cooktop 36'' Black - NGM5664UC
Gas Cooktop 36'' Black
Model: NGM5664UC




Gas Cooktop 36'' Black
Model: NGM5664UC
Replaced By
Key Features
Slide your pans from burner to burner
Automatic re-ignition
Dishwasher-safe grates
Controls Gas Supply
Easy to clean, low-profile design
Heavy-Duty Metal Knobs: for a premium look and feel.
Continuous Cast Iron Grates: makes it easy to slide pots & pans from burner to burner.
Electronic Re-Ignition: automatically re-ignites the burner in case the flame goes out.Close
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Slide your pans from burner to burner
The full-width continuous cast iron grate design makes sliding heavy pots easier around the cooking surface.
Automatic re-ignition
The electronic re-ignition feature will automatically re-ignite the burner in case the flame goes out during use.
Dishwasher-safe grates
A special enameling process allows the grates to be washed directly in the dishwasher instead of by hand for easier clean up.
Controls Gas Supply
FlameSafe thermocouple sensor will shut off the gas supply if flame is extinguished – for added safety and peace of mind.
Easy to clean, low-profile design
The low-profile cooking surface provides a timeless, streamlined look while keeping spills contained and makes clean-up easier than ever
Heavy-Duty Metal Knobs: for a premium look and feel.
Continuous Cast Iron Grates: makes it easy to slide pots & pans from burner to burner.
Electronic Re-Ignition: automatically re-ignites the burner in case the flame goes out.Close
The electronic re-ignition feature will automatically re-ignite the burner in case the flame goes out during use.
Dishwasher-Safe Grates: conveniently place your grates in the dishwasher for easy clean-up.Close
A special enameling process allows the grates to be washed directly in the dishwasher instead of by hand for easier clean up.
FlameSafe Thermocouple Sensor: shuts off the gas supply if flame is extinguished.
Heavy-Duty Metal Knobs:
for a premium look and feel.
Continuous Cast Iron Grates:
makes it easy to slide pots & pans from burner to burner.
Electronic Re-Ignition:
automatically re-ignites the burner in case the flame goes out.
Dishwasher-Safe Grates:
conveniently place your grates in the dishwasher for easy clean-up.
FlameSafe Thermocouple Sensor:
shuts off the gas supply if flame is extinguished.
Specifications
Safety
| Safety | Without Safety |
Accessories
| Included Accessories | 3 x cast iron pan support |
General
| Total NG BTUs | 57500 Btu |
| Total LP BTUs | 47800 Btu |
Installation
| Overall Appliance Dimensions (HxWxD) (in) | 3 13/16'' x 37'' x 21 1/4'' |
| Required Cutout Size (HxWxD) (in) | 3 13/16'' x 34 15/16'' x 19 1/8'' |
| Alternative Gas Type (Nozzle Set Included) | Liquid gas 27,5 mbar (USA) |
| Plug Type | 120V-3 prong |
| Power Cord Length | 60'' |
| Fuse protection | 15 A |
| Volts | 120 V |
| Product Packaging Dimensions (HxWxD) | 8 3/8'' x 43 1/8'' x 24 3/4'' |
| Gas type preset | Natural gas 15 mbar (USA) |
Design
| Surface Materials | Porcelain, Steel |
| Grate Materials | Cast Iron with Rubber Feet |
| Location of Control Panel | Front |
Comfort and Convenience
| Number of Gas Burners | 0 |
| Sealed Burners | yes |
| Special Features | Reignition |
| Griddle | no |
| ADA Compliant (When Installed to ADA requirements) | no |
| OptiSim® Burner | no |
Dimensions & Weight
| Width | 37 in. |
| Height | 3.81 in. |
| Length | 21.25 in. |
| Weight | 46 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 42 in. |
| Shipping Height | 8.81 in. |
| Shipping Length | 26.25 in. |
| Shipping Weight | 86 lbs. |
| Total of Shipping Weight | 86 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 1.73 ft³ |
| Dimensional Weight | 21.57 lbs. |
| Total of Cubes | 1.73 ft³ |
| Total of Dimensional Weight | 21.57 lbs. |
