500 Series - NIT5065UC
500 Series
Model: NIT5065UC










500 Series
Model: NIT5065UC
Key Features
Speed up your cooking.
Child Lock for unauthorized use
Faster, efficient cooking with induction.
Select your ideal temperature
Boil water quickly with SpeedBoost
17 Levels of Power
More space for more cooking
Power Boost: up to 35% faster heating compared to highest power level.Close
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Speed up your cooking.
When you want to get quick and easy meals on the table even faster, Power Boost can help. This practical feature adds a boost of power for ultra-quick heating. Use it on your induction hob to boil large quantities of water – and heat up to 35% faster compared to the highest power level.
Child Lock for unauthorized use
Now kids can no longer turn on the hob by mistake. The Child Lock function prevents unauthorized use of the hob with just one long press of a button.
Faster, efficient cooking with induction.
Induction technology directly heats your pots and pans instead of the cooktop itself for faster cooking and precise results.
Select your ideal temperature
The precise temperature selection results in consistent, perfect results whether you’re searing a steak, grilling salmon or veggies, or delicately melting chocolate.
Boil water quickly with SpeedBoost
Adds a boost of power to your burner so you can boil a pot of water faster or heat a pan up quickly to get ready for searing.
17 Levels of Power
17 different power levels that are designed for your cooking needs. Each one features a different heat level, anywhere from a simmer to a boil.
More space for more cooking
Large 11" cooking zone offers 3,700W of power for precise results.
Power Boost: up to 35% faster heating compared to highest power level.Close
When you want to get quick and easy meals on the table even faster, Power Boost can help. This practical feature adds a boost of power for ultra-quick heating. Use it on your induction hob to boil large quantities of water – and heat up to 35% faster compared to the highest power level.
Panel Lock: locks the control panel to prevent accidental changes in settingsClose
Now kids can no longer turn on the hob by mistake. The Child Lock function prevents unauthorized use of the hob with just one long press of a button.
Induction: faster than gas and electric cooktops. Precise cooking, easy cleaning and more efficient.Close
Induction technology directly heats your pots and pans instead of the cooktop itself for faster cooking and precise results.
Precise Temperature Control: Induction cooking offers a range of numbered heat levels for precise temperature and heat levels every timeClose
Count-Up Timer: allows you to accurately time each step of your recipe.
Power Boost:
up to 35% faster heating compared to highest power level.
Timer with switch-off function:
turns off the assigned cooking zone after the set time.
Panel Lock:
locks the control panel to prevent accidental changes in settings
Induction Technology:
saves in average 20% energy compared to radiant technology.
Precise Temperature Control:
Induction cooking offers a range of numbered heat levels for precise temperature and heat levels every time
Specifications
Construction type
| Color of frame | Stainless Steel |
| Color of Surface | Black, Stainless Steel |
| Design | Built-in |
| Design - line | Convenience frame |
| Number of electric elements | 0 |
| Number of electric cooking zones | 0 |
| Type of frame | Convenience frame |
| Number of halogen elements | 0 |
| Installation Type | Built-in |
| Total Number of Heating Elements | 4 |
| Number of radiant elements | 0 |
| Number of electric warming zones | 0 |
General
| Energy source | Electric |
| Type of Control | TouchControl Basic |
| Safety | Auto Safety Shutoff, Childproof Lock, Panel Lock, pan recognition |
| Features | 17 power levels, powerBoost |
| Total Number of Heating Elements | 4 |
| Cooking Zone Flexibility | Ring Zone |
| Power Levels | 17 Power Levels |
| Watts | 7200 W |
| ADA Compliant (When Installed to ADA requirements) | no |
Cooking zone 1
| Location of heating element | front left |
Cooking zone 2
| Location of 2nd heating element | center left |
Cooking zone 3
| Location of 3rd heating element | back left |
Cooking zone 4
| Location of 4th heating element | middle back |
Cooking zone 5
| Location of 5th heating element | back right |
Cooking zone 6
| Location of 6th heating element | center right |
Cooking zone 7
| Location of 7th heating element | front right |
Cooking zone 8
| Location of 8th heating element | front middle / central |
Cooking zone 9
| Location of 9th heating element | front centre/cent |
Safety
| Residual Heat Indicator | Yes |
| Safety | Panel Lock, Childproof Lock, pan recognition, Auto Safety Shutoff |
Connection
| Frequency | 60 Hz |
| Energy source | Electric |
| Power Cord Length | 37" |
| Watts | 7,200 W |
Design
| Frame Type | Frame |
| Color of Frame | Stainless Steel |
| Color | Black |
| Type of Control | Direct Select |
Flexibility of Cooking Zones
| Total Number of Heating Elements | 4 |
| Cooking Zone Flexibility | Ring Zone |
| Automatic Linking/ Separating of Cooking Zones | no |
| TeppanyakiPro™ | no |
| TeppanyakiPro™ | no |
Comfort and Convenience
| Power Levels | 17 Power Levels |
| Timer | Switch-off timer (on appliance), Kitchen Timer |
| Keep Warm | no |
| Automatic Cookware Detection | no |
| ADA Compliant (When Installed to ADA requirements) | no |
Time Saving and Efficiency
| SpeedBoost® | All |
| Automatic Setting Transfer | no |
| Increase/ Decrease Power Level via Moving Pot | No |
| Powermove | no |
| Frying Sensor Technology | Not Applicable |
| Cooking Sensor Ready | no |
| SpeedBoost® | All |
Connectivity
| Home Connect™ | no |
| Cooktop-Based Hood Control | no |
| Home Connect™ | no |
Dimensions & Weight
| Width | 30 in. |
| Height | - |
| Length | 21.25 in. |
| Weight | 41 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | - |
| Shipping Length | 26.25 in. |
| Shipping Weight | 81 lbs. |
| Total of Shipping Weight | 81 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | - |
| Dimensional Weight | - |
| Total of Cubes | - |
| Total of Dimensional Weight | - |
