208-230V 9,000 BTU Ductless Console Indoor Unit208-230V 9,000 BTU Ductless Console Indoor Unit - USYF09UCDWA
208-230V 9,000 BTU Ductless Console Indoor Unit208-230V 9,000 BTU Ductless Console Indoor Unit
Model: USYF09UCDWA
208-230V 9,000 BTU Ductless Console Indoor Unit208-230V 9,000 BTU Ductless Console Indoor Unit
Model: USYF09UCDWA
Color : Other
Key Features
Warm Start
Room Temperature Display
Turbo Mode
ODU Compatibility
Blue Fin
Quiet Mode
2-Way Supply Air
Compact Size
Description
Available from Barrys Appliance, serving customers throughout New Jersey & Surrounding Areas.
Features
Warm Start
Get warm quickly with a fan that will not blow cold air during heating mode startup.
Room Temperature Display
Dual seven segment display on the front panel provides an easy to read temperature display.
Turbo Mode
Cool or heat your room quickly using turbo mode.
ODU Compatibility
Compatible with select Single and Multi Zone Outdoor Units.
Blue Fin
A hydrophilic aluminum fin ensures condensing water flows away smoothly.
Quiet Mode
Minimize indoor noise while maintaining comfort levels using quiet mode.
2-Way Supply Air
Selector switch allows you the option to close floor vent and have airflow out of the top vent only.
Compact Size
With a height of up to 30", console units provide flexibility to install in different low wall applications.
SmartHQ Home
Built-In WiFi allows you to monitor status, adjust temperature, and set cooling and heating schedules from anywhere using your smartphone
Certifications
ADA Compliant
Specifications
POWER / RATINGS
| Voltage/Hertz/Phase | 208-230/60/1 |
| Cooling Rated Capacity BTU/Hr | 9,000 |
FEATURES
| Product Type | Multi Zone |
| Product Type | Single Zone |
| Style | Console |
| Fan Speeds CFM | 147 |
| Fan Speeds CFM | 176 |
| Fan Speeds CFM | 205 |
| Fan Speeds CFM | 235 |
| Fan Speeds CFM | 264 |
| Series | Indoor Units (Compatible with Select Series) |
| Connected Capabilities | Amazon Alexa |
| Connected Capabilities | Google Home |
| Drainpipe Size (in) | 1 1/4" |
| Indoor Sound Level | 43 dBA |
| Indoor Sound Level | 40 dBA |
| Indoor Sound Level | 37 dBA |
| Indoor Sound Level | 34 dBA |
| Indoor Sound Level | 31 dBA |
| Unit Type | Indoor |
| WiFi Connect | Built-In |
| WiFi Connect | SmartHQ Home Built-In |
WEIGHTS & DIMENSIONS
| Liquid O.D. Refrigerant Line | 1/4" |
| Suction O.D. Refrigerant Line | 3/8" |
| Approximate Shipping Weight | 43.34 lb |
| Net Weight | 36.3 lb |
| Overall Depth | 8.25 in |
| Overall Height | 23.75 in |
| Overall Width | 27.5 in |
APPEARANCE
| Color Appearance | White |
Dimensions & Weight
| Width | 27.5 in. |
| Height | 23.63 in. |
| Length | 8.88 in. |
| Weight | 36.3 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 32.5 in. |
| Shipping Height | 28.63 in. |
| Shipping Length | 13.88 in. |
| Shipping Weight | 76.3 lbs. |
| Total of Shipping Weight | 76.3 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 3.34 ft³ |
| Dimensional Weight | 41.48 lbs. |
| Total of Cubes | 3.34 ft³ |
| Total of Dimensional Weight | 41.48 lbs. |
Capacity
| Max. Heating Capacity -22°F BTU/Hr | 4,000 Btu |
Features
| Connected Capabilities | Amazon Alexa |
| Connected Capabilities | Google Home |
| Drainpipe Size (in) | 1 1/4" |
| Indoor Sound Level | 43 dBA |
| Indoor Sound Level | 40 dBA |
| Indoor Sound Level | 37 dBA |
| Indoor Sound Level | 34 dBA |
| Indoor Sound Level | 31 dBA |
| Unit Type | Indoor |
| WiFi Connect | Built-In |
| WiFi Connect | SmartHQ Home Built-In |
Weights & Dimensions
| Approximate Shipping Weight | 43.34 lb |
| Net Weight | 36.3 lb |
CAPACITY
| Max. Heating Capacity -22°F BTU/Hr | 4,000 Btu |
WARRANTY
| Parts Warranty | 5-Year limited parts warranty |
| Parts Warranty | 10-Year registered limited parts warranty |
| Labor Warranty | No Warranty |
| Warranty Notes | See written warranty for full details |
